AL-E037 SINGLE PHASE AC PHASE CONTROL BY TRIAC-DIAC TRAINER


Discription:

SCOPE OF LEARNING:

  • Single Phase AC Phase Control By Triac-Diac
    • TECHNICAL SPECIFICATIONS:

Power Supplies:

  • Isolated Supply 0-220V AT 2A.
    • Operated on Mains power 230V, 50Hz +10%

Components are mounted on the panels are:

  • TRIAC BT136
  • DIAC DB3
  • AC Phase Control by RC Firing Circuit.
  • Snubber Circuit.

SALIENT FEATURES:

  • 10:1 Potential Divider for CRO
  • Protection Cover
  • Bulb As Load
  • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
    • Instruction manual.
    • Patch Cords 4mm Both.
    • High Voltage Test Points are Provided With 4mm Safety Sockets
    • The trainer is housed in Metal cabinet.
    • Size of the trainer set 12”x8”

OPTIONAL ACCESSORIES:

  • CRO

Category:
POWER ELECTRONICS & DRIVE LAB
product Name:
AL-E037 SINGLE PHASE AC PHASE CONTROL BY TRIAC-DIAC TRAINER
