AL-E140 THERMISTOR TEMPERATURE TRANSDUCER TRAINER
SCOPE OF LEARNING:
Study of THERMISTOR as Temperature Measuring Transducer
- Voltmeter 200mV DC.
- DC Supply IC Regulated +12V, +5V DC, 150mA.
- Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
- Variable Resistor
- 741 IC
- Electrical Kettle as Heating Element.
- Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
- Fuse for Short Circuit protection
- Instruction manual.
- Connections are brought out through 2mm Colored Sockets.
- Patch Cords 2mm.
- The trainer is housed in ABS Plastic cabinet.
- Size of the trainer set 12”x8”
- Digital Thermometer
