AL-E200 SCR THREE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER TRAINER
Experiment: SCR Three Phase Half-Full Controlled Bridge Converters Using Firing Techniques with R Load.
- Kit comprises of 3 Digital Meters:
- Voltmeter 2000V AC
- Voltmeter 2000V DC
- Ammeter 2A DC
- Power Supply +15Vat 150mA
- Isolated 415/110V AT 1A.
- Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
- Resistive Load (Lamp and Resistor 20W)
- MCB for Short Circuit protection
Components are mounted on the panels are:
- SCR TYN604
- Diode 1N5408 and BA159
- AC Phase Control by Gate Control Firing Circuit R,Y and B Phases.
- Instruction manual.
- Protection Cover.
- Operated on Mains power 415V, 50Hz.
- Patch Cords 2mm and 4mm Both.
- High Voltage Test Points are Provided With 4mm Safety Sockets
- Supply provided through the 3 pin computer socket with appropriate fuse
- The trainer is housed in Metal cabinet.
- Size of the trainer set 14”x12” and 18’’x12’’
