Higher Education Instruments Manufacturers & Exporters Ambey International!

Product Overview

AL-E277B 3PHASE RESISTIVE LOAD (15A)


Description:

 TECHNICAL SPECIFICATIONS:

  • 5 Control switches given board for current control for Each Phase
  • Each switch controls 1A current.
  • 15Nos of Rheostats are mounted inside the cabinet having value of 1A.
  • Rating of Rheostats are 440Ohm,1A at 415V
  • Current Meter is provided for Load Measurement
  • Operating Voltage 415V, 50Hz AC (3Phase)

SALIENT FEATURES:

  • Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols.
  • Instruction manual.
  • 3 Phase Indications with 25mm Multi Colored Indicators.
  • Patch Cords 4mm (Heavy Duty)
  • High Voltage Test Points are Provided With 4mm Safety Sockets
  • The trainer is housed in Metal cabinet.
  • Short Circuit protection with 4Pole MCB.
  • Size of the trainer set 18”x24”
  • Easy to move as wheels are given
  • FAN INSTALLED FOR COOLING

OPTIONAL ACCESSORIES:

  • NO





Category:
ELECTRICAL ENGINEERING
Product Name:
AL-E277B 3PHASE RESISTIVE LOAD (15A)
Download PDF:
No Catalog Attached
