AL-E422C THREE PHASE AC SYNCHRONOUS MACHINE TRAINER
THREE PHASE AC SYNCHRONOUS MACHINE TRAINER (SPEED CONTROL)
SCOPE OF LEARNING:
- Speed Control AC Synchronous Motor
- Synchronous Motor as Induction Motor
- TECHNICAL SPECIFICATIONS:
- AC Power Supply 0-415V AT 4A (External)
- DC Power Supply 0-230V AT 2A (Field)
- Operated on Mains power 415V, 50Hz +10%
- RPM Meter With Proximity Sensor
Components are mounted on the panels are:
- Variac 2A (1Phase)
- DOL Starter
- Emergency Stop Switch.
- Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols.
- The trainer is housed in Modular Based Rack Type Aluminum Extruded Metal cabinet.
- Instruction manual.
- Patch Cords 4mm (Heavy Duty)
- Power Indication through 25mm Colored Indicators
- High Voltage Test Points are Provided With 4mm Safety Sockets
- The trainer is housed in Metal cabinet.
- Protection with Emergency Stop.
- Short Circuit protection with the MCB.
- Size of the trainer set 30”x24”
- AC Synchronous Motor 1HP, 230V, AC & 1440 RPM.
