AL-E475B SINGLE PHASE PWM INVERTER USING POWER TRANSISTOR


Discription:

SCOPE OF LEARNING:

  • Single Phase PWM Inverter Using Power Transistor
    •  TECHNICAL SPECIFICATIONS:

Power Supplies:

  • Power Supply +15Vat 150mA
  • Isolated Supply 0-12V AT 2A.
    • Operated on Mains power 230V, 50Hz +10%

Components are mounted on the panels are:

  • Power Transistor BU508
  • PWM Pulse Generator Circuit.
  • Frequency Control Through Potentiometer

SALIENT FEATURES:

  • 10:1 Potential Divider for CRO
  • Protection Cover
  •  60W Bulb As Load
  • Fuse for Short Circuit protection
  • Over Load Protection Through Circuit Breaker
  • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
    • Instruction manual.
    • Patch Cords 4mm.
    • High Voltage Test Points are Provided With 4mm Safety Sockets
    • The trainer is housed in Metal cabinet.
    • Size of the trainer set 15”x11”

OPTIONAL ACCESSORIES:

  • CRO



Category:
POWER ELECTRONICS & DRIVE LAB
