Product Overview

AL-E690A DIGITAL AC MILLIVOLTMETER (TRUE RMS)


Discription:

SCOPE OF LEARNING:

  • AC voltage measurements from high impedance sources

TECHNICAL SPECIFICATIONS:

Meters:

  • 3½ digit, 7 segment LED with auto polarity and

Decimal indication

Power Supplies:

  • Inbuilt DC Regulated Power Supply.
    • Operated on Mains power 230V, 50Hz +10%

Range:

  • 20Mv,  200mV, 2V & 20V with 100% over-ranging
  •  Resolution         :               1µV
  • Accuracy            :               ±0.2% ±1 digit
  • Stability               :               Within ±1 digit
  • Input Impedance  :          >1000MOhm (10M Ohm on 10V range)
  • SALIENT FEATURES:
    • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
    • Fuse for Short Circuit protection
    • Instruction manual.
    • Connections are brought out through BNC Connector.
    • The trainer is housed in Metal Cabinet.
    • Size of the trainer set 13”x6”

OPTIONAL

Category:
ADVANCE PHYSICS
product Name:
AL-E690A DIGITAL AC MILLIVOLTMETER (TRUE RMS)
Download PDF:
No Catalog Attached
