AL-E818 AD590 TEMPERATURE TRANSDUCER TRAINER


Discription:

SCOPE OF LEARNING:

Study of AD590 as Temperature Measuring Transducer

TECHNICAL SPECIFICATIONS:

Digital Meters:

  • Voltmeter 200mV DC.

Power Supplies:

  • DC Supply IC Regulated +12V, +5V DC, 150mA.
    • Operated on Mains power 230V, 50Hz +10%

Components are mounted on the panels are:

  • AD590 as Sensor With Probe
  • Variable Resistor
  • 741 IC
  • Electrical Kettle as Heating Element.
  • Thermometer

SALIENT FEATURES:

  • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
  • Fuse for Short Circuit protection
  • Instruction manual.
  • Connections are brought out through 2mm Colored Sockets.
  • Patch Cords 2mm.
  • The trainer is housed in ABS Plastic cabinet.
  • Size of the trainer set 12”x8”

OPTIONAL ACCESSORIES:

  • Multimeter
  • Digital Thermometer
